Splits the refrigerant, not the electricity bill.

This split refrigerant heat pump is built for effcient hot water without draining your power. Designed to consume less energy while delivering maximum performance, it’s perfect for flats and compact spaces. The split design with copper tubing allows flexible installation, making it ideal where space is tight but comfort is non-negotiable.

Model	HXHP-SPLIT-300L(3.7KW)	HXHP-SPLIT-500L(7.2KW)
Nominal capacity	300Liter	500Liter
Outer diameter	580mm	710mm
Weight (when empty)	HP Unit 30kg, Tank 85kg	HP Unit 48kg, Tank 135kg
Weight (filled)	385kg	635kg
Tank Height	1875mm	1910mm
Heatpump Size	765L x 260D x 530H mm	800L x 300D x 560H mm
Inner Tank material	American Ferro Glass Lined	American Ferro Glass Lined
Operating Air temperature range (HP Mode)	-2˚C to 43˚C	-2˚C to 43˚C
Maximum pressure	8 bar	8 bar
Max. Hot water temperature (HP + Backup Heater)	70˚C	70˚C
Electrical/Power Specifications
Rated Input – ECO mode	0.870kW	1.750kW
Heating Output – ECO mode	3.7kW	7.2kW
Electrical backup	2kW	3kW
Rated Input – HP + backup	2.87kW	4.75kW
Heating Output HP + backup	5.7kW	10.2kW
Running Current (including backup heater)	18Amps	30Amps
Voltage and Frequency	230V / 50Hz	230V / 50Hz
Others
Refrigerant type	R410A / 1050g	R410A / 1950g
Sound power level	<52dB(A)	<55dB(A)
Coefficient of performance (COP)	4.25	4.25
Hot water generation per hour HP Mode (35˚C delta)	90 LPH	176 LPH
IP Rating	IPX4	IPX4
Water inlet / Outlet size	G 3/4”	G 1”

*Test Condition : Ambient Temp. : 15˚C | Cold Water Inlet Temp. : 20˚C | Hot Water Temp. : 55˚C
